KA127R77DM63L4Detailed Information

prevnext

KA127R77DM63L4

TEL：Email:[email protected]

详细信息

Keywords: 1. 1 kw powering with a perforated axle axle reduction box_ka127r77dm63l4_ka127r77drrs100l4

KA127R77DM63L4Geared motor reducer parameters：

Model	Slowdown ratio	Power	Transfers	Twisting	Weight	Strength	Safety factor
KA127R77DM63L4	14975	0.18KW	0.09r/min	15700N.m	422kg	74400N	0.80
KA127R77DM63L4	12440	0.18KW	0.11r/min	13100N.m	422kg	79100N	1 .00
KA127R77DM63L4	10915	0.18KW	0.12r/min	11500N.m	422kg	80000N	1.15
KA127R77DM63L4	9819	0.18KW	0.13r/min	10300N.m	422kg	80500N	1.25
KA127R77DM63L4	8443	0.18KW	0.16r/min	8870N.m	422kg	81100N	1.45
KA127R77DM63L4	7482	0.18KW	0.18r/min	7880N.m	422kg	81500N	1.65
KA127R77DM63L4	6565	0.18KW	0.20r/min	6910N.m	422kg	81800N	1.90
KA127R77DM63L4	5804	0.18KW	0.23r/min	5880N.m	422kg	82100N	2.20
KA127R77DM63L4	5027	0.18KW	0.26r/min	5210N.m	422kg	82300N	2.50
KA127R77DM63L4	4423	0.18KW	0.30r/min	4480N.m	422kg	82400N	2.90
KA127R77DM63L4	3889	0.18KW	0.34r/min	3900N.m	422kg	82500N	3.30
KA127R77DM63L4	3311	0.18KW	0.40r/min	3240N.m	422kg	82600N	4.00

Ka127r77drs100l4 power-reducing machine parameters:

Model	Slowdown ratio	Power	Transfers	Twisting	Weight	Strength	Safety factor
KA127R77DRS100L4	790	3KW	1.80r/min	14200N.m	451kg	77400N	0.90
KA127R77DRS100L4	704	3KW	2.10r/min	12700N.m	451kg	79300N	1.00
KA127R77DRS100L4	610	3KW	2.40r/min	11000N.m	451kg	80200N	1.20
KA127R77DRS100L4	549	3KW	2.60r/min	9960N.m	451kg	80700N	1.30
KA127R77DRS100L4	477	3KW	3.00r/min	8620N.m	451kg	81200N	1.50
KA127R77DRS100L4	418	3KW	3.50r/min	7590N.m	451kg	81600N	1.70

KA127R77DM63L4Speeding machine type:

K127r77dm63l4 bottom foot fitted with tilt gears - umbrella gear reduction power

Ka127br77dm63l4 foot hollow axis with tilt gears - umbrella gear-reducing power

The kv127 br77dm63l4 bottom foot larvae axis is equipped with tilt gears - an umbrella gear-reducing motor

Kh127 br77dm63l4 foot hollow axle locks with tilt gears.Right-angle shaft reducer motor

Frf127r77dm63l4b5 installation of tilt gear - umbrella gear reduction power

Kaf127r77dm63l4b5 french aerocentric axle is equipped with tilt gears - umbrella gear reduction power

Kvf127r77dm63l4b5franco-axis installation of tilt gear - umbrella gear deviation engine

Khf127r77dm63l4b5farland axle locks fitted with tilt gears - an umbrella gear-reducing power plant

Ka127r77dm63l4 hollow axle tilt gears - an umbrella gear decelerator power plant

Kv127r77dm63l4 installation of tilt gear - umbrella gear-reducing power

Kh127r77dm63l4 empty axle locks slashing gears - umbrella gear deceleration power

The kt127r77dm63l4 hollow axle is equipped with tilt gears - an umbrella gear decelerator

Kaz127r77dm63l4b14 installation of tilt gear - umbrella gear reduction power

Kvz127r77dm63l4b14franco-axis installation of tilt gear - umbrella gear deviation engine

Khz127r77dm63l4b14 french axle locks fitted with tilt gears - umbrella gear reduction power

KA127R77DM63L4Induction Motor 3Ph motors installed size drawings

Ka127r77dm63l4 deviation power plant, three days' appointmentThrough-hole shaft reducer

Through-hole shaft reducer,Hollow shaft reducer,Double output hole reducer Geared motor

KA37 Reducer, KA47 Reducer, KA57 Reducer, KA67 Reducer, KA77 Reducer, KA87 Reducer, KA97 Gear Reducer, KA107 Gear Reducer, KA127 Gear Reducer, KA157 Gear Reducer, KA167 Gear Reducer, KA187 Gear Reducer Helical bewel gearbox

KA Series gear reducers can be paired with variable frequency motors, brake motors, explosion-proof motors, servo motors, AC motors, DC motors, three-phase motors, and single-phase motors ranging from 0.12KW to 200KW
