KA97R57DR100LC4Detailed Information
Keyword: 15kw power with an empty axle brake_ka97r57dr100lc4_ka97r57dve80k4
KA97R57DR100LC4Geared motor reducer parameters：
| Model | Slowdown ratio | Power | Transfers | Twisting | Weight | Strength | Safety factor |
| KA97R57DR100LC4 | 258 | 3KW | 5.60r/min | 4740N.m | 183kg | 40000N | 0.90 |
| KA97R57DR100LC4 | 232 | 3KW | 6.30r/min | 4270N.m | 183kg | 40000N | 1.00 |
| KA97R57DR100LC4 | 199 | 3KW | 7.30r/min | 3660N.m | 183kg | 40000N | 1.15 |
Ka97r57dve80k4reducing motor parameters:
| Model | Slowdown ratio | Power | Transfers | Twisting | Weight | Strength | Safety factor |
| KA97R57DVE80K4 | 1430 | 0.55KW | 0.96r/min | 4860N.m | 163kg | 40000N | 0.90 |
| KA97R57DVE80K4 | 1261 | 0.55KW | 1.10r/min | 4360N.m | 163kg | 40000N | 1.00 |
| KA97R57DVE80K4 | 1102 | 0.55KW | 1.20r/min | 3810N.m | 163kg | 40000N | 1.15 |
| KA97R57DVE80K4 | 957 | 0.55KW | 1.40r/min | 3340N.m | 163kg | 40000N | 1.30 |
| KA97R57DVE80K4 | 855 | 0.55KW | 1.60r/min | 2990N.m | 163kg | 40000N | 1.45 |
| KA97R57DVE80K4 | 573 | 0.55KW | 2.40r/min | 1980N.m | 163kg | 40000N | 2.20 |
| KA97R57DVE80K4 | 743 | 0.55KW | 1.90r/min | 2500N.m | 163kg | 40000N | 1.70 |
| KA97R57DVE80K4 | 652 | 0.55KW | 2.10r/min | 2210N.m | 163kg | 40000N | 1.95 |
| KA97R57DVE80K4 | 504 | 0.55KW | 2.70r/min | 1690N.m | 163kg | 40000N | 2.50 |
| KA97R57DVE80K4 | 437 | 0.55KW | 3.20r/min | 1450N.m | 163kg | 40000N | 3.00 |
| KA97R57DVE80K4 | 382 | 0.55KW | 3.60r/min | 1300N.m | 163kg | 40000N | 3.30 |
| KA97R57DVE80K4 | 305 | 0.55KW | 4.50r/min | 1040N.m | 163kg | 40000N | 4.10 |
KA97R57DR100LC4Speeding machine type:
K97r57dr100lc4 bottom foot is equipped with tilt gears - an umbrella gear decelerator
Ka97r57dr100lc4 foot hollow axis with tilt gear - umbrella gear-reducing power
Kv97br57dr100lc4 foot larvae axis installation of tilt gear - umbrella gear decelerator
Kh97br57dr100lc4 foot hollow axis locks with tilt gears -Right-angle shaft reducer motor
Frf97r57dr100lc4b5 installation of tilt gear - umbrella gear deceleration power
Kaf97r57dr100lc4b5 french aerocentric axis with tilt gears - umbrella gear reduction power
Kvf97r57dr100lc4b5-franco cardiac axis installed with tilt gears - umbrella gear reduction power
Khf97r57dr100lc4b5 french axle locks fitted with tilt gears - umbrella gear reduction power
Ka97r57dr100lc4 hollow axle tilt gears - an umbrella gear deceleration power
Kv97r57dr100lc4 space cores equipped with tilt gears - umbrella gear-reducing power
Kh97r57dr100lc4 sky axe locked tilt gear - umbrella gear deviation engine
Installation of tilt gear on kt97r57dr100lc4 hollow axle - umbrella gear reduction power
Kaz97r57dr100lc4b14 installation of tilt gear - umbrella gear reduction power
Kvz97r57dr100lc4b14 franco-axis installation of tilt gear - umbrella gear deviation engine
Khz97r57dr100lc4b14 french axle locks fitted with tilt gears - an umbrella gear-reducing power plant
KA97R57DR100LC4Induction Motor 3Ph motors installed size drawings
Ka97r57dr100lc4 power-reducing plantThrough-hole shaft reducer
Through-hole shaft reducer,Hollow shaft reducer,Double output hole reducer Geared motor
KA37 Reducer, KA47 Reducer, KA57 Reducer, KA67 Reducer, KA77 Reducer, KA87 Reducer, KA97 Gear Reducer, KA107 Gear Reducer, KA127 Gear Reducer, KA157 Gear Reducer, KA167 Gear Reducer, KA187 Gear Reducer Helical bewel gearbox
KA Series gear reducers can be paired with variable frequency motors, brake motors, explosion-proof motors, servo motors, AC motors, DC motors, three-phase motors, and single-phase motors ranging from 0.12KW to 200KW
