KH167R107DT225S4Detailed Information
Keyword: 230v turbostats_kh167r107dt225s4_kh167r107dre160l4
KH167R107DT225S4Geared motor reducer parameters：
| Model | Slowdown ratio | Power | Transfers | Twisting | Weight | Strength | Safety factor |
| KH167R107DT225S4 | 180 | 37KW | 8.20r/min | 39800N.m | 1,468kg | 150000N | 0.80 |
| KH167R107DT225S4 | 160 | 37KW | 9.20r/min | 35800N.m | 1,468kg | 150000N | 0.90 |
| KH167R107DT225S4 | 135 | 37KW | 11.0r/min | 30300N.m | 1,468kg | 150000N | 1.05 |
| KH167R107DT225S4 | 118 | 37KW | 12.0r/min | 26400N.m | 1,468kg | 150000N | 1.20 |
KH167R107DRE160L4Speed-down electrical parameters:
| Model | Slowdown ratio | Power | Transfers | Twisting | Weight | Strength | Safety factor |
| KH167R107DRE160L4 | 318 | 15KW | 4.60r/min | 28900N.m | 1,303kg | 150000N | 1.10 |
| KH167R107DRE160L4 | 278 | 15KW | 5.30r/min | 25200N.m | 1,303kg | 150000N | 1.25 |
| KH167R107DRE160L4 | 244 | 15KW | 6.00r/min | 21800N.m | 1,303kg | 150000N | 1.45 |
| KH167R107DRE160L4 | 213 | 15KW | 6.90r/min | 19000N.m | 1,303kg | 150000N | 1.70 |
| KH167R107DRE160L4 | 206 | 15KW | 7.10r/min | 18600N.m | 1,303kg | 150000N | 1.70 |
| KH167R107DRE160L4 | 180 | 15KW | 8.10r/min | 16000N.m | 1,303kg | 150000N | 2.00 |
| KH167R107DRE160L4 | 160 | 15KW | 9.20r/min | 14500N.m | 1,303kg | 150000N | 2.20 |
KH167R107DT225S4Speeding machine type:
K167r107dt225s4 bottom foot is fitted with tilt gears - umbrella gear reduction power
Ka167br107dt225s4 foot hollow axis with tilt gears - umbrella gear reduction power
Kv167br107dt225s4 bottom foot larvae axis with tilt gears - umbrella gear reduction power
Kh167br107dt225s4 bottom-foot hollow-axis locks with tilt gears -Right-angle shaft reducer motor
Frf167r107dt225s4b5 installation of tilt gear - umbrella gear-reducing power
Kaf167r107dt225s4b5 french aerocentric axis is equipped with tilt gears - umbrella gear reduction power
Kvf167r107dt225s4b5francocardix installation of tilt gear - umbrella gear-reducing power
Khf167r107dt225s4b5franium axle lockboard installation of tilt gears - umbrella gear deviation engine
Ka167r107dt225s4 hollow axle tilt gears - an umbrella gear reduction power
The kv167r107dt225s4 spaced axles is equipped with tilt gears - umbrella gear reduction power
Kh167r107dt225s4 empty axle locks slashing gears - umbrella gear reduction power
Installation of tilt gears on kt167r107dt225s4 hollow axle - umbrella gear reduction power
Kaz167r107dt225s4b14 installation of tilt gear - umbrella gear reduction power
Installation of tilt gears - umbrella gear deviation electrics on the franco cardiac axe
Khz167r107dt225s4b14 french axle locks fitted with tilt gears - umbrella gear-reducing power
KH167R107DT225S4Induction Motor 3Ph motors installed size drawings
Kh167r107dt225s4 deviation power plant, three days' advance appointmentGear with motor
Gear with motor,AC Motor&Gear,Motor gearheads,Motor reductor Geared motor
KAF37 gear reducer, KAF47 gear reducer, KAF57 gear reducer, KAF67 gear reducer, KAF77 gear reducer, KAF87 gear reducer, KAF97 gear reducer, KAF107 Gear Reducer, KAF127 Gear Reducer, KAF157 Gear Reducer, KAF167 Gear Reducer, KAF187 Gear Reducer Helical bewel gearbox
KAF Series gear reducers can be paired with variable frequency motors, brake motors, explosion-proof motors, servo motors, AC motors, DC motors, three-phase motors, and single-phase motors ranging from 0.12KW to 200KW
标签: 230v turbo-pattern brake kh167r107dt225s4 kh167r107dr160l4
Documentation related to this product / Related DownLoad
| Product Document Name | Click to download |
| KH167R107DT225S4减速机样本 |
|
| KH167R107DT225S4减速机三维图纸 |
|
