SA97R57DT80S4Detailed Information
Keyword: 0. 18 kw night gear brakes_sa97r57dt80s4_sa97r57drrs100lc4
SA97R57DT80S4Geared motor reducer parameters：
| Model | Slowdown ratio | Power | Transfers | Twisting | Weight | Strength | Safety factor |
| SA97R57DT80S4 | 1223 | 0.75KW | 1.20r/min | 4710N.m | 204kg | 23400N | 0.90 |
| SA97R57DT80S4 | 1070 | 0.75KW | 1.30r/min | 4130N.m | 204kg | 32200N | 1.00 |
| SA97R57DT80S4 | 928 | 0.75KW | 1.60r/min | 3550N.m | 204kg | 34000N | 1.20 |
| SA97R57DT80S4 | 824 | 0.75KW | 1.70r/min | 3140N.m | 204kg | 34700N | 1.35 |
| SA97R57DT80S4 | 714 | 0.75KW | 2.00r/min | 2240N.m | 204kg | 35900N | 1.85 |
| SA97R57DT80S4 | 626 | 0.75KW | 2.30r/min | 2380N.m | 204kg | 35800N | 1.75 |
| SA97R57DT80S4 | 538 | 0.75KW | 2.70r/min | 2040N.m | 204kg | 36100N | 2.00 |
| SA97R57DT80S4 | 484 | 0.75KW | 3.00r/min | 1850N.m | 204kg | 36300N | 2.30 |
SA97R57DRS100LC4Geared motor reducer parameters：
| Model | Slowdown ratio | Power | Transfers | Twisting | Weight | Strength | Safety factor |
| SA97R57DRS100LC4 | 287 | 3KW | 5.10r/min | 4580N.m | 223kg | 25700N | 0.90 |
| SA97R57DRS100LC4 | 252 | 3KW | 5.80r/min | 4020N.m | 223kg | 33100N | 1.05 |
| SA97R57DRS100LC4 | 219 | 3KW | 6.60r/min | 3510N.m | 223kg | 34100N | 1.20 |
| SA97R57DRS100LC4 | 205 | 3KW | 7.10r/min | 3300N.m | 223kg | 34500N | 1.25 |
Sa97r57dt80s4 motor deceleratorType:
S97r57dt80s4 foot installation - slash gearServo motor reducer
Sa97r57dt80s4 sky axe installation - tilt snail strangler
Saf97r57dt80s4 is a b5 installation-slash snail brake
Saz97r57dt80s4 is thereducing machine for the b14 aerocentric axle snail snail
Sf97r57dt80s4 is the b5-silver snail deviator
Sh97r57dt80s4 is an empty axle lock-board installation - a snail-slasher
Shf97r57dt80s4 is a b5 franium axle locker installation - a sledge snail brake
Shz97r57dt80s4 is a b14 franium axle locker installation - a sledge snail brake
Sa97/tr57dt80s4 rotation arm hollow axis installation -- slough snail brakes
Sh97/tr57dt80s4 is an axle lock lock installation for a sledge snail brake
Sa97br57dt80s bottom foot hollow axis installation -- snail snail brakes
Sh97br57dt80s bottom foot hollow axle lock-drive installation -- snail brake
St97r57dt80s4 solid axis export shaft arm installation - slashed gear snail stifler
Sa97r57dt80s4 motor deceleratorInstall size drawings
Sa97r57dt80s4 motor deceleratorProduction plant display: three days' appointment for the factoryLevel-IIreducing machine
Bevel gear reducer,Helical gear reducer,worm gear motor speed reducer Geared motor
SA37 gearbox, SA47 gearbox, SA57 gearbox, SA67 gearbox, SA77 gearbox, SA87 gearbox, SA97 Gear Reducer Servo motor reducer
SA Series gear reducers can be paired with variable frequency motors, brake motors, explosion-proof motors, servo motors, AC motors, DC motors, three-phase motors, and single-phase motors ranging from 0.12KW to 22KW
